Brief Introduction of LA16.0150Y Compressor Clutch

LA16.0150Y is linnig magnetic bus ac clutch for Eberspächer, Konvekta and Webasto bus ac compressor cooling solution.


OEM Code of LINNIG LA16. 0150Y

81066306076

Eberspächer - Sütrak (Carrier)

30,04,02,238
30,04,04,238-00
30.04.02.238
30.04.04.238-00
300402238
30040423800
300404238-00
8867010003800
88670100038-00
88-67-01-00038-00

Konvekta
H13-002-583-L
H13-002-583-L-01
H13002583-L
H13002583-L-01
H13002583L
H13002583L01

Webasto-Spheros
68803A
68803B
68803C

Man(Neoplan-Neoman)
81.06630-6076
12004224
36.77954-6027
8106630-6076
11160195
3677954-6027
81066306076
36779546027

Thermo King
H243010421

Linnig (Kendrion Markdorf)
LA16.150Y-F
LA16150Y-F
LA16.0150Y-F
LA160150Y-F

Autoclima:
40456160150

Application:
LA16.0150 2G "B" Ø 203


Technical of LINNIG LA16. 0150Y Bus AC Magnetic Clutch



Description	LA16.0150 2 Grooves "B" Ø 203
Note	Man / Konvekta / Carrier-Sutrak / Webasto / Thermoking
OEM Clutch Code	LA16.0150Y
Voltage	24V
Number of grooves	2
Groove width	2x17 mm
Groove type	2G B
Section Groove (S)	2x16,3 mm
External diameter (a)	2x210 mm
Internal diameter (b)	2x203 mm
OEM Code Coil	01.021.8
Autoclima Code Coil	40456010218
