Remanufactured Bitzer 4nfcy Compressor
Model:
Bitzer 4nfcy remanufactured
Cylinders:
4
We're here to help: Easy ways to get the answers you need.
Categories
Relate Product
.jpg)
Product Tags
Brief Introduction of remanufactured bitzer 4nfcy
Remanufactured bitzer 4nfcy compressor is very hot sale in bitzer 4 cylinders compressor series. Besides that KingClima can also provide other models of Bitzer 4 cylinders compressors as following type:
● Remanufactured Compressor Bitzer 4nfcy
● Remanufactured Bitzer 4ufcy
● Remanufactured Bitzer 4pfcy
OEM Code of Bitzer 4 Cylinders Bus AC Compressor
| OEM Code of Bitzer 4nfcy | Konvekta:H13002903, SUTRAK:240101213 |
| OEM Code of Bitzer-4TFC(Y) | Konvekta: H13002901 |
| OEM Code of Bitzer-4PFY | Autoclima:40425007,Konvekta:H13002902,SUTRAK:240101208 |
Photo: package of bitzer 4nfcy remanufactured compressor
Technical of Remanufactured Bitzer 4nfcy Compressor
| Models | Bitzer 4NFCY |
| OEM Code | Konvekta:H1300290, SUTRAK:240101213 |
| Number of cylinders | 4 |
| Bore | 70mm |
| Stroke | 42mm |
| Cylinder volume | 647 cm3 |
| Displacement(1450/3000 rpm) | 56.20/116.40 m3/h |
| Allowed speed range | 500...3500 1/min |
| Magnetic clutch 12V or 24V DC | LA16 Option |
| Mass Moment of intertia | 0.0043kgm2 |
| Max. pressure(LP/HP)1) | 19/28 bar |
| Connection suction line SV | 35MM - 1 3/8" |
| Connection discharge line DV | 35MM - 1 3/8" |
| Lubrication | oil pump |
| Oil type R134a | BSE 55 (Option) |
| Oil type R22 | B5.2 (Standard) |
| Oil charge | 2.0 dm3 |
| Crankcase heater | 70W 12V or 24V DC (Option) |
| Pressure relief valve | Standard |
| Net Weight | 33kgs |
| Gross Weight | 35kgs |
| Dimensions | 385*325*370mm |
| Packing Size | 440*350*400mm |
